S image of VT-HPC-1-11/M-P-00/00

VT-HPC-1-11/M-P-00/00

by Bosch Rexroth Indramat
$7,957.96 - $7,957.96
$7,957.96
$7,957.96 - $7,957.96
$7,957.96

Available, Shipping Varies

The VT-HPC-1-11/M-P-00/00 controller from Bosch Rexroth Indramat is a member of the VT-HPC Piston Pump Controllers series designed for precision axial piston variable displacement pump control. Housed in a robust Honeywell Enclosure OTB122 with an IP66 rating, this unit measures 19 × 13 × 8 cm and has a net weight of 1.2 kg. It operates on a nominal 24 V DC (20 V – 28 V DC) power supply and features a High-Level Voltage input range of 11 V to UB with a Low-Level Voltage range of −3 V to 5 V. The controller draws a minimal Current Consumption (High) of 2 mA–15 mA at high input status and supports a dedicated Digital Inputs: 4 for versatile signal handling. These specifications underpin a compact, lightweight design that simplifies integration into factory automation systems.

The VT-HPC-1-11/M-P-00/00 delivers a Maximum Power Output of 3.2 W at 55 °C ambient temperature and 1.2 W at 65 °C elevated temperature, ensuring consistent performance under varied thermal conditions. Electrostatic and electromagnetic disturbances are constrained by a Maximum Residual Ripple of 5 Vpp (40–400 Hz) on the supply line. With a built-in protection concept and rapid on-line readiness, the unit achieves full control capability in under 15 seconds. Both Certificate Number (atex): Baseefa07ATEX0142X and Certificate Number (iecex): IECEx BAS 07.0034X attest to compliance with hazardous-area standards. A Packaging Weight of 1.5 kg and a solid mechanical design complete the performance profile, making it ideal for high-precision hydraulic control.

Engineered for demanding industrial environments, the VT-HPC-1-11/M-P-00/00 offers seamless integration via Ethernet-based parameterization and compatibility with Powerlink, PROFINET RT, EtherNet/IP, Sercos III, and EtherCAT networks. Its resilient enclosure and robust electrical architecture ensure reliable operation amidst vibration, moisture, and temperature variations. Certified for explosive atmospheres, this controller supports safe deployment in petrochemical, marine, and mining applications. Serviceability is enhanced by straightforward diagnostics and remote configuration, reducing downtime and maintenance costs. Overall, this piston pump controller elevates hydraulic system accuracy and uptime across a broad range of automation tasks.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Certificate Number (atex)

Baseefa07ATEX0142X

Certificate Number (iecex)

IECEx BAS 07.0034X

Current Consumption (High)

2 mA – 15 mA

Digital Inputs

4

Dimensions

19 × 13 × 8 cm

Enclosure Type

Honeywell Enclosure OTB122

High-Level Voltage

11 V to UB

Ip Rating

IP66

Low-Level Voltage

–3 V to 5 V

Maximum Power Output

3.2 W at 55°C ambient temperature

Maximum Power Output (elevated Temperature)

1.2 W at 65°C ambient temperature

Maximum Residual Ripple

5 Vpp (40 – 400 Hz)

Net Weight

1.2 kg

Operating Voltage

24 V DC (20 V - 28 V DC)

Packaging Weight

1.5 kg
