P image of VT-MSPA 2-525-10-V0

VT-MSPA 2-525-10-V0

by Bosch Rexroth Indramat
$1,827.35 - $1,827.35
$1,827.35
$1,827.35 - $1,827.35
$1,827.35

Available, Shipping Varies

The Bosch Rexroth Indramat VT-MSPA 2-525-10-V0 is a solid and reliable industrial component that includes analog amplifier modules, digital axis controllers, among others. It operates at a nominal voltage of 24 VDC with current consumption of less than 2 A, and a solenoid current analog output that operates at 0 to +/- 2.5 mA. The component is specially designed for installation on top hat rails with three tension spring plug-in connections for easy electrical linkage. Also featuring IP20 certification, the model must be set to operate within a temperature range of 0 to +60 degrees Centigrade. Weighing only 0.14 kilograms, this module boots up in under a second. During assembly, ensure ventilation openings are at least 2 cm from coverings to allow for proper ventilation. Note the ambient temperature regulation, if more than 50 degrees Celsius, spaces between assemblies should be maintained at least 1 cm apart. Lastly, the VT-MSPA 2-525-10-V0 should be stored at a temperature range of +5 to +40 degrees centigrade, ensuring UV protection.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Type

Analog Amplifier Module

Model

VT-MSPA 2-525-10-V0

Solenoid Current Output

0 to +/- 2.5 mA

Minimum Impedance Load

1000 ohms

Operating Voltage

24 VDC

Current Consumption

< 2 A

Solenoid Output Maximum Current

1 A

Clock Frequency Setting Range

95 to 505 Hz

Certification

IP20

Installation

Suitable for top hat rails

Connection Type

Three tension spring plug-in

Start Time

< 1 second

Weight

0.14 kilograms

Operating Temperature Range

0 to +60 degree centigrade

Installation

Vertical

Ventilation Opening Distance

Minimum 2 cm away from coverings or walls

Ambient Temperature Tolerance

up to 50 degrees Celsius with 1 cm space between assemblies

Digital Input (active)

11 V

Digital Input (inactive)

-3 to +5 V

Additional Features

Clock generator and current controller

Storage Temperature Range

+5 to +40 degrees centigrade with UV protection.
