VT-MSPA1-1-12/V0/0

Name: VT-MSPA1-1-12/V0/0
Brand: Bosch Rexroth Indramat
Price: 4412.54 USD
Availability: InStock

by Bosch Rexroth Indramat

$1,661.22 - $4,412.54

$1,661.22

$1,661.22 - $4,412.54

$1,661.22

The Bosch Rexroth Indramat VT-MSPA1-1-12/V0/0 from the VT-MSPA Drives series is a compact analog amplifier module offering a Voltage Supply Range: nominal 24 VDC (+40% to -20%) with Reverse Polarity Protection: Yes and an Operating Voltage: 24 VDC. Its Internal Power Supply: Equipped with current limiter and Output Short Circuit Protection: Enabled ensure reliable performance under demanding industrial conditions. Command inputs of Command Value Input: 0 to ±10 V or 4 to 20 mA are monitored via Led Status Displays. With Maximum Power Consumption: < 50 VA, Switch-on Current: < 4 A, adjustable Ramp Generator Adjustment: Separate adjustments for up and down ramps, Dimensions: 25 x 79 x 85.5 mm, and a Weight: 0.14 kg, this module combines versatility and efficiency for precise solenoid control.

Contact Us

Email: sales@servosupplier.com

Phone Number: 1-888-551-3082

International: 1-919-443-0207

Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Characteristic Curve Generation

Enabled

Command Value Input

0 to ±10 V or 4 to 20 mA

Dimensions

25 x 79 x 85.5 mm

External Fuse

3.15 A time-lag

Internal Power Supply

Equipped with current limiter

Led Status Displays

Available for monitoring

Maximum Current Consumption

< 1.3 A

Maximum Power Consumption

< 50 VA

Operating Voltage

24 VDC

Output Short Circuit Protection

Enabled

Ramp Generator Adjustment

Separate adjustments for up and down ramps

Reverse Polarity Protection

Yes

Switch-on Current

< 4 A

Voltage Supply Range

Nominal 24 VDC (+40% to -20%)

Weight

0.14 kg
