S image of VT-MSPA1-11-1X-V0-0

VT-MSPA1-11-1X-V0-0

by Bosch Rexroth Indramat
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The VT-MSPA1-11-1X-V0-0, a top-tier analog amplifier module, is developed by industry leader Bosch Rexroth Indramat. Exceptional in its modular design, it can be effortlessly integrated into control cabinets using standard top hat rails. This model boasts a ramp generator with a limited control output rise, facilitating the accuracy of command signal values. Trimmers "t" and "t >" manage the rise and drop times of these values. The device is rated for an operational temperature of 0 to 50 degrees Celsius. It comes with a differential command value input with a 100 Kohm resistance and a voltage range of 0 to +10 V. The module also features an advanced diagnostic system for monitoring solenoid lines and safeguarding against short circuits and overcurrent. It functions as a pressure valve-operating analog amplifier and needs to be stationed at least a meter from electromagnetic devices. It utilizes a PWM signal, generated from its power output stage, to supply the solenoid, hence ensuring precise current control.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Line Includes

Analog amplifier modules, synchronous motors, drive controllers, digital axis controllers, power supply modules

Product Model

VT-MSPA1-11-1X-V0-0

Module Options

Ramp generator with a restricted control output increase

Trimmers

"t" for rising command value time, "t >" for dropping command value voltage time

Operating Temperature Range

0 to 50 degrees Celsius

Input Specifications

Differential command value input with a 100 Kohm resistance and a 0 to +10 V voltage range

Fault Diagnostic System

Monitors the solenoid lines for cable damage, short circuits, output stage overcurrent

Type

Pressure valve-operating analog amplifier

Modular Design

Facilitates the addition of conventional top hat rails in control cabinets

Distance Requirement

Should be more than one meter away from radios and other electromagnetic equipment

Solenoid Current Output

Current rating of 1.9 A and a frequency ranging from 180 to 450 Hz

Power Output Stage

Produces a PWM signal that is supplied to the solenoid

Current Controller Function

Measures solenoid current, compares to the control output, corrects the disparity
