S image of VT-MSPA1-21-F5-000-000

VT-MSPA1-21-F5-000-000

by Bosch Rexroth Indramat
$2,451.08 - $2,451.08
$2,451.08
$2,451.08 - $2,451.08
$2,451.08

In Stock, Ships 1 - 3 Days

The Bosch Rexroth Indramat VT-MSPA1-21-F5-000-000 is a valuable amplifier from the VT-MSPA series specifically designed for single-solenoid proportional valves. Aiding a broad range of operations, this amplifier boasts of protective features like reverse polarity protection for voltage and short-circuit prevention. It comes equipped with an adjustable ramp generator, characteristic curve generator, LED status displays, and zero-point setting. Measuring sockets aid in monitoring current values, while the three tension spring plug-in connectors provide external connections. Unique to this amplifier is its onboard power supply with a current limiter to prevent current peaks. The 24V DC supply voltage is backed by 2 Amps of maximum current consumption. Compact in design, it weighs 0.14 kilograms and complies with IP20 protection standards. However, it requires an external enclosure for outdoor usage alongside careful monitoring of environment conditions such as temperature and humidity.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product

VT-MSPA1-21-F5-000-000

Type

VT-MSPA Series Valve Amplifier

Compatibility

Proportional valves with a single solenoid

Current Command Value Range

4 to 20 milliamps

Features

Reverse polarity protection, Separately adjustable up and down times for ramp generator, Zero point setting, Command value adjustment, Output short-circuit protection, Characteristic curve generator, LED status displays

Connections

Three tension spring plug-in connectors

Mounting

Top hat rails

Power Supply Unit

Internal with current limiter

Supply Voltage

24 Volts DC

Max Current Consumption

2 Amps

Max Power Consumption

48 VA

Peak Inrush Current

4 Amps

Start-up Time

Less than a second

Protection Rating

IP20

Weight

0.14 kilograms

Max Temperature Change Rate

5 degrees Celsius per minute

Transport Temperature Range

-40 to 80 degrees Celsius

Storage Temperature Range with UV Protection

5 to 40 degrees Celsius

Required Humidity

10 to 95%

Maximum Altitude

2000 meters

Maximum Transport Shock

15 g for 11 milliseconds
