VT-MSPA1-2X-A5-000-000

Original price $1,761.00 - Original price $1,761.00
Original price
$1,761.00
$1,761.00 - $1,761.00
Current price $1,761.00
Available, Shipping Varies
Request a quote
The VT-MSPA1-2X-A5-000-000 is a valve amplifier, manufactured by Bosch Rexroth Indramat, known for their industrial drive control systems and motion control products. The amplifier is specifically designed for proportional valves without electrical position feedback, and it features a maximum current limitation of 1 A. This product is particularly suitable for various industrial hydraulic applications, capable of precisely controlling pump controls and proportional valves. It's designed for explosion protected valves with one or two solenoids and allows adjustment of all valve parameters and optimization. The system has a modular design, with less than 48 W power consumption and maximum current consumption less than 2 A. It features zero point calibration, command value attenuator, and an adjustable ramp generator with a startup time of less than a second. The product is built to withstand tough ambient conditions and is in compliance with vibration, shock protection, and IP 20 ingress protection standards.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: Valve Amplifier
  • Model: VT-MSPA1-2X-A5-000-000
  • Maximum Current Limitation: 1 A
  • Use: Proportional valves without electrical position feedback
  • Design Advantage: Explosion protected valves with one or two solenoids
  • Suitable For: Different types of industrial hydraulics
  • Max Power Consumption: 48 W
  • Max Current Consumption: 2 A
  • Fuse: 3.15 A external fuse
  • Feature: Zero point calibration, command value attenuator, adjust the ramp generator
  • Start Up Time: Less than a second
  • Vibration and Shock Protection: In compliance with industry standards
  • Outer Enclosure Material: Glass fiber reinforced polyamide plastic
  • Ingress Protection: IP 20
  • Design Standards: Sine test and noise test in accordance with DIN EN standards
