VT-MSPA1-2X-F5-000-000

Original price $2,693.50 - Original price $2,693.50
Original price
$2,693.50
$2,693.50 - $2,693.50
Current price $2,693.50
Available, Shipping Varies
Request a quote
As a product from Bosch Rexroth Indramat's component series 2X, the VT-MSPA1-2X-F5-000-000 is a specialized valve amplifier built for proportional valves and pump controls without electrical position feedback. It features adjustable parameters and on-device storage for valve characteristic curves. Capable of optimizing proportional valves using a singular solenoid, this amplifier works within a 40 to 20 milliamps command value current range. The unit, designed to assemble on top hat rails, gets wired through three tension spring plug-in connectors and operates on a 24-volt DC power supply, with maximum allowable variation from 18 to 36 volts DC, inclusive of a 2.5 Vpp residual ripple at the most. The protection features include a built-in making current limiter, polarity inversion, and a 3.5 Amp time-lag fuse. The unit powers up in under a second and operates within 0 to 60 degree Celsius, but can store between -40 to 70 degrees Celsius. A UV-protected storage allows for 5 to 40 degrees Celsius. However, excessive UV exposure can cause color changes in its partly UV-resistant housing. Measuring 99 x 22.5 x 114 mm, the unit should be installed vertically.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Code: VT-MSPA1-2X-F5-000-000
  • Product Type: Valve Amplifier
  • Series: 2X
  • Valve Compatibility: Proportional Valves With One Solenoid
  • Command Value Range: 40 to 20 milliamps
  • Installation: Top Hat Rails
  • Electrical Connection: Three Tension Spring Plug-in Connectors
  • Supply Voltage: 24 Volts DC (18 to 36 Volts DC)
  • Admissible Residual Ripple: 2.5 Vpp
  • Power Draw: 48 Watts Maximum
  • Current Draw: 2 Amps Maximum
  • Switch-On Current: 4 Amps Maximum
  • Fuse Rating: 3.5 Amps
  • Startup Time: Less Than 1 Second
  • Protection Class: IP20
  • Ambient Temperature Range: 0 to 60 degrees Celsius (Operation), -40 to 70 degrees Celsius (Storage), 5 to 40 degrees Celsius (Storage with UV Protection)
  • Housing: Partly UV Resistant
  • Installation Position: Vertical
  • Dimensions: 99 x 22.5 x 114 millimeters
