S image of VT-MSPA1-30-1X-V0-0

VT-MSPA1-30-1X-V0-0

by Bosch Rexroth Indramat
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The VT-MSPA1-30-1X-V0-0, a product of Bosch Rexroth Indramat, is an analog amplifier from the Bosch VT-MSPA1 series, primarily used to control direct operation proportional pressure valves. Specifically tailored for DBE(M) 30-3X and DRE(M) 30-4X valves, its features include an in-built ramp generator, characteristic curve generator, differential input, and an LED display. Additionally, this amplifier includes zero-point potentiometer with inverse-polarity protection and short-circuit protection for output power. Its operating voltage ranges from 21V DC to 35V DC, with a nominal value of 24V DC. With a maximum power consumption of 25 VA and a current consumption under 1 Amp, it mounts on a TH 35-7.5 top hat rail per EN 60715 standards. The amplifier has a protection class of IP20 and weighs 0.15 kg, measuring 25 x 70 x 85.5 mm. It operates in a temperature range from 0 to +50 degrees Celsius and should only be managed by trained professionals.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Bosch Rexroth Indramat

Product Type

VT-MSPA1 series analog amplifier

Model Number

VT-MSPA1-30-1X-V0-0

Suitable For

Controlling direct operation proportional pressure valves

Compatible Valve Models

DBE(M) 30-3X, DRE(M) 30-4X

Key Features

Inverse-polarity protection, Differential input, Ramp generator, Dither generator with fixed frequency, Zero point potentiometer, Characteristic curve generator, Output short-circuit protection, LED display

Upper Operating Voltage Limit

35 Volts DC

Lower Operating Voltage Limit

21 Volts DC

Nominal Operating Voltage

24 Volts DC

Maximum Power Consumption

25 VA

Maximum Current Consumption

1 Amp

Mounting Method

TH 35-7-5 top hat rail according to EN 60715

Product Protection Class

IP20 according to EN 60529

Shipping Weight

0.15 kilograms

Dimensions

25 x 70 x 85.5 millimeters

Working Temperature

0 to +50 degrees Celsius

Storage Temperature

-25 to +85 degrees Celsius

Wiring Requirement

Amplifier module may only be wired when de-energised

Radio Distance Requirement

Greater than 1 meter

Command Value Lines Requirement

Should be screened and sufficiently separated from power cables

Solenoid Lines Requirement

Should be screened

External Smoothing Capacitor Requirement

2200 microfarads for strong fluctuations in operating voltage

User Requirement

Only trained professionals should handle and operate the amplifier module.
