manufacturer image of VT-MSPA2-1-1X-V0-0

VT-MSPA2-1-1X-V0-0

by Bosch Rexroth Indramat
$3,228.75 - $3,228.75
$3,228.75
$3,228.75 - $3,228.75
$3,228.75
Available, Shipping Varies
The VT-MSPA2-1-1X-V0-0, produced by Bosch Rexroth Indramat, is an analog amplifier belonging to their VT-MSPA2 line. Specialized for controlling direct operated proportional directional valves without electric position feedback, it is particularly suitable for controlling 4WRA6 and 4WRA10 (both series 2X) valves. Operating at a nominal voltage of 24 Volts DC within a range of 18 to 35 Volts DC, its current draw and power consumption do not exceed 2 Amps and 48 VA respectively. It features a thermal overload protection fuse and distinct command values for both analog and digital inputs. Connections are made via 12 screw terminals and it's designed for top hat rail mounting. Final specifications include IP20 protection class, 40 x 79 x 85.5 mm dimensions, and 140-gram weight. Ambient operating temperatures are between 0 and 50 degrees Celsius. Installation requires disconnected power supply and a minimum 1-meter distance from aerial lines, radios, and radar systems.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: Analog Amplifier
  • Product Line: VT-MSPA2
  • Suitability: Controlling direct operated proportional directional valves without electric position feedback
  • Specific Use: Controlling valves 4WRA6 and 4WRA10 (component series 2X)
  • Product Version: Standard
  • Nominal Operating Voltage: 24 Volts DC
  • Operating Voltage Range: 18 to 35 Volts DC
  • Current Draw: Not exceed 2 Amps
  • Power Consumption: Not exceed 48 VA
  • Safety Feature: Fuse for thermal overload protection
  • Command Value Voltage Range (Analog Input): 0 to ±10 Volts
  • Command Value Voltage Range (Digital Inputs ON Level): 8.5 Volts
  • Command Value Voltage Range (Digital Inputs OFF Level): 0 to 6.5 Volts
  • Product Connections: 12 screw terminals
  • Mounting Design: Suitable for top hat rail mounting (TH 35-7.5 as per EN 60715)
  • Protection Class: IP20 according to EN 60529
  • Approximate Dimensions (mm): 40 x 79 x 85.5
  • Approximate Weight: 140 grams
  • Operating Ambient Temperature: 0 to 50 degrees Celsius
  • Storage Ambient Temperature: -25 to 70 degrees Celsius
  • Usage Precaution: Must be wired only when disconnected from power supply
  • Distance Precaution: At least 1 meter from aerial lines, radios, radar systems
  • Optional Feature: External smoothing capacitor can be used to minimize the effects of power supply fluctuations.
