The Rexroth Bosch Indramat VT1610S3X is a lightweight servo amplifier designed to control pilot servo valves without the need for LVDT feedback, making it ideal for closed loop applications. Its built-in voltage stabilizer ensures stable performance, while three internal potentiometers accessible via the faceplate offer easy adjustment. A faceplate-mounted ammeter facilitates current monitoring. This amplifier boasts a Euro-card supplying call-ups with voltage, a power supply current less than 200mA, and power supply voltage of +/-15V. It is compatible with UK 2 or VE 102 system cards to enhance control capabilities. Key components include a voltage regulator, summing amplifier, proportional amplifier, voltage control, servo pilot valve, and dither oscillator. Note that radio transmitters should remain at least 1 meter away as it is sensitive to radio frequency interference. When connecting or disconnecting the card, always switch off the amplifier to prevent damage.
30 Day Warranty
Technical Specifications
  • Manufacturer: Rexroth Bosch Indramat
  • Product Type: Servo Amplifier
  • Usage/Application: Control of pilot servo valves
  • Technological Use: Closed loop applications
  • Weight: 0.15kg
  • Special Features: Voltage stabilizer, Internal potentiometers, Faceplate mounted ammeter
  • Power Supply Current: <200mA
  • Power Supply Voltage: +/-15V
  • Working Ambient Temperature: 0 - 50 degrees
  • Storage Temperature: -20 to 70 degrees
  • Additional Control Input: Yes
  • Compatible With: UK 2, VE 102 system cards
  • Main Components: Voltage regulator, summing amplifier, proportional amplifier, voltage control, servo pilot valve, dither oscillator
  • Radio Frequency Interference: Sensitive
  • Ideal Distance Between Radio Transmitters and Card: 1 meter
  • Voltage Wires: Needs Shielding
