X20CA0E61.01000
The X20CA0E61.01000 motor cable from B & R Automation is a robust solution in the CM16 Motor Cables series, designed to deliver reliable power and communication in industrial automation environments. With a standard length of 10 meters, this cable supports a power supply voltage of 24 VDC and features an Ethernet Powerlink bus interface for synchronized real-time data exchange. Constructed with a durable outer jacket in RAL 9005 (black) and a halogen-free inner jacket, it withstands mechanical strain and harsh conditions. The cable assembly integrates RJ45 connectors on both ends, ensuring straightforward connectivity to controllers and devices without additional adapters.
This cable’s technical capabilities are demonstrated by its current consumption of approx. 80 mA (at 24 VDC), delivered through push-in terminals that simplify installation and maintenance. The connector type RJ45 supports data transfer rates up to 1000 Mbit/s (from unstructured data), while the cable’s shielding—comprising aluminum foil and copper braiding—protects against electromagnetic interference. With a conductor impedance of less than 145 Ω/km at 68 °F and insulation impedance exceeding 5 GΩ/km at the same temperature, the cable maintains signal integrity under demanding electrical loads. The polyethylene wire insulation and tinned copper strands (26/7 AWG) further reinforce its performance in both static and dynamic applications.
Operational features include a compact dimension of 25 x 99 x 73 mm for the connector heads, a protection class IP20 rating at the connectors when properly plugged in, and a weight of approx. 100 g plus a linear mass of 0.058 kg/m that facilitates easy handling and routing in control cabinets. The cable tolerates ambient temperatures ranging from operating temperature of 0 to 55 °C to storage temperature of –25 to 70 °C, and it is qualified for installations up to 2000 m above sea level. Minimum bend radii of 4× diameter for fixed runs and 8× diameter for flexible runs ensure reliable performance without undue stress on the conductors. Its plastic housing material and silicone-free construction comply with industry safety requirements and minimize maintenance.
Integration into automation systems is seamless, with the cable’s DIN rail mounting option enabling tidy cable channel organization within control panels. The combination of Ethernet Powerlink compatibility and standardized RJ45 interfaces makes the X20CA0E61.01000 ideal for drive systems, motor feedback loops, and I/O modules in packaging, material handling, and process control applications. Its robust design and adherence to RoHS directives ensure long service life and regulatory compliance, empowering engineers to deploy high-performance networks with confidence.
