The XSJ-230-02 from Copley Controls features a 3-phase MOSFET inverter and delivers 15 kHz center-weighted PWM output. Part of the XENUS Digital Loop Modules, it measures 126 x 89 x 53 mm and weighs 0.30 kg while supporting CANopen and RS-232 communications.
It provides fully digital control loops for current, velocity, and position and includes 14 digital inputs with 4 outputs. The drive operates on 85–264 VAC and offers internal MOSFET-based regeneration capabilities.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Certifications
EN 55011, EN 61000-6-1, EN 61010-1, UL 508C
Communications
CANopen, RS-232
Continuous Current
1 A DC (0.7 A RMS, sinusoidal, ±5%)
Control Loops
current, velocity & position (fully digital)
Control Modes
Indexer, point-to-point, PVT
Digital I/O
14 inputs, 4 outputs
Dimensions (in)
5.0 x 3.5 x 2.1 in
Feedback
resolver
Input Voltage
85–264 VAC, 50–60 Hz
Inverter Type
3-phase MOSFET
Operating Temp Range
0 to +45 °C
Peak Current
2 A DC (1.4 A RMS, sinusoidal, ±5%)
PWM
15 kHz center-weighted, space-vector modulation
Regeneration
internal MOSFET dissipator
Size
126 x 89 x 53 mm
Weight
0.30 kg (0.67 lb)
