ZS1090-1006
The Beckhoff ZS1090-1006 connector from the ZS Motion Accessories series is a robust M8 field plug assembly designed for Ethernet/EtherCAT applications in industrial automation. This 4-pin male plug features A-coded contacts, a durable metal body with IP67 protection, and integrated shielding for reliable signal integrity. It accommodates cable diameters from 4.9 to 6.5 mm and wires up to AWG20 (0.5 mm²) via secure screw connections. With an overall length of 47 mm and a diameter of 14 mm, it ensures easy assembly through a straightforward process of sliding the clamping nut, cable seal, and housing over the cable, stripping the conductors to length, inserting them to the end stop, and tightening the M2 screw to the specified torque of 0.1 Nm, providing a dependable and durable interconnect solution for harsh industrial environments.
