S image of S60600-NA

S60600-NA

by Danaher
$4,147.88 - $4,147.88
$4,147.88
$4,147.88 - $4,147.88
$4,147.88

In Stock, Ships 1 - 3 Days

The Danaher-manufactured S60600-NA, also known as SERVOSTAR 606, is a servo drive amplifier belonging to Kollmorgen's S600 series. This sophisticated component consumes an input current of 6 Amp RMS and does not feature an Electr option or expansion slot. Despite this, it is a critical part of most of Kollmorgen's digital servo motor-based systems while being capable of compatibility with other drive-based motion control systems. The amplifier can be deftly managed via its PC-based interface software. It has a rated output current of 6.0 Amps RMS and can peak at 12.0 Amps RMS, while the permissible DC bus voltage ranges from 290-675 volts. It includes in-built overvoltage protection that is triggered at anything exceeding 450 volts. Compact and lightweight at just 4 kg, it allows for versatile placement. The S60600-NA's load inductance ranges from 25 mH to 150 mH. Its in-built safety features include soft-start electrical separation, short-circuit protection, phase-failure monitoring and overvoltage recognition.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Product Name

S60600-NA

Manufacturer

Danaher

Product Series

S600

Product Type

Servo Drive Amplifiers

Input Current

6 Amp RMS

Electr Option

None

Expansion Slot

None

Software

PC based interface compatible

RMS Rated Output Current

6.0 Amps

RMS Maximum Peak Output Current

12.0 Amps

RMS Rated DC Bus Voltage

290-675 Volts

Protection Type

Integrated overvoltage

Weight

4 Kg

Dimension

275 mm length, 70 mm Width, 65 mm depth

Maximum Load Inductance Rating

150 mH

Minimum Load Inductance Rating

25 mH

Mounting Method

Vertical preferred

Additional Features

Short-circuit protection, Overvoltage recognition, Phase-failure monitoring, Real-time temperature monitoring.
