B506-2001

The Danaher B506-2001 timer and controller, part of the Timers and Controllers series, delivers precise timing solutions for industrial automation with a universal 90-240 VAC 50/60 Hz supply voltage. Featuring 17 Programmable Modes, the B506-2001 adapts to a wide range of control sequences, from simple delay functions to complex cyclic operations. A user-friendly interface integrates a Dual line, 4 digit, 7 segment LED, 8mm high display for clear viewing of parameters and status messages. This module provides two 2 SPDT (5 amp), 15 ms max latency relay outputs for reliable switching, ensuring timely intervention across demanding processes. Housed in a compact 48mm x 48mm x 85mm enclosure, the B506-2001 combines flexibility and performance in a standardized form factor.

Technical details include a programmable Time Ranges from 0.01 seconds to 999 hours, accommodating both ultra-short and extended intervals. The device maintains Repeat Accuracy of ±0.01%, guaranteeing consistent timing cycles in critical applications. Non-volatile EEPROM memory retains settings for up to 10 years without power, eliminating the need for frequent reconfiguration. Operating within 0°C to 55°C, and with storage extremes from -40°C to 90°C, this controller withstands varied environmental conditions. Power consumption remains minimal at Less than 5 VA, contributing to overall energy efficiency in automated systems.

Operational features emphasize resilience and reliability: the front panel is rated IEC IP65, protecting against dust ingress and water spray for use on rugged factory floors. A humidity tolerance of 10% to 90% RH (non-condensing) ensures stable function in fluctuating ambient conditions. Installation is straightforward, supporting both Panel (45x45mm cutout) or DIN rail mounting, while a lightweight footprint of 100 grams (3.5 ounces) reduces mechanical load on support structures. Response latency of the relay outputs stays within 15 ms max, enabling high-speed control loops and precise synchronization with other control elements.

System integration is simplified through standardized connectivity and dimensional conformity, making the B506-2001 ideal for OEMs and retrofit applications. Seamless incorporation into Danaher PLC networks and third-party controllers allows extensive interoperability across manufacturing lines. The combination of high ingress protection, wide supply range, and flexible timing modes targets applications in packaging machinery, conveyor control, process batching, and safety interlock systems. Engineers deploying the B506-2001 benefit from a robust, accurate, and versatile timing solution optimized for modern industrial automation environments.
