B506-7001

The Danaher B506-7001 timer/controller from the Timers and Controllers series delivers precise timing and rugged reliability in a compact panel-mount package. Designed for industrial automation environments, this controller integrates dual SPDT relays and a bright LED display to manage timing sequences with ease. Its 1/16 DIN form factor and versatile supply range accommodate a wide variety of control panels and power systems. The unit’s robust front panel enclosure and straightforward operator interface simplify installation and daily operation. With over a dozen critical specifications engineered for dependable performance, the B506-7001 offers a balanced solution for timing logic, sequence control, and process monitoring.

Detailed technical specifications define the B506-7001’s capabilities in exacting terms. The controller mounts in a Mounting: Panel 1/16 DIN (48 mm x 48 mm), 45 mm x 45 mm cutout and connects to a Supply Voltage: 90–240 VAC, 50/60 Hz source. Power consumption is limited to Power Consumption: < 10 VA, minimizing impact on upstream supplies. Time parameters span multiple modes—Time Ranges: Hrs, Mins, Secs, Hrs:Mins, Mins:Secs—and offer selectable Resolution: XXXX or X.XXX (hrs, mins, secs) for fine adaptation to process requirements. The Display Type: Dual-line, 4-digit, 7-segment LED, 8 mm high provides clear status feedback, while the input circuitry accepts Input Type: Start & Reset, NPN or Dry Contact signals with an Impedance: 10 kΩ.

Operational features emphasize responsive control and high repeatability. The controller achieves an Activation Time: 21 ms for rapid task initiation and features a Relay Output Latency: 15 ms to ensure synchronized actuation of external devices. Two Output Type: Relay, 2 SPDT (5 A) modules handle switching loads up to Relay Output Rating: 5 A without auxiliary hardware. Thermal design and component selection allow continuous operation from Operating Temperature: 0 °C to 55 °C (32 °F to 131 °F). The unit delivers Repeat Accuracy: ±0.01 %, maintaining consistent cycle times over extended duty periods. Front panel protection rated Front Panel Rating: IEC IP65 shields internal electronics from dust and splash, supporting reliable performance in washdown or dusty plant-floor conditions.

The B506-7001 integrates seamlessly into existing control architectures and supports common industrial applications, including batch process control, environmental chamber management, and basic machine sequencing. Standard 1/16 DIN mounting and universal power compatibility reduce design complexity and spare parts inventories. The rugged IP65-rated bezel and compact outline accommodate harsh environments and space-constrained panels. With its combination of precision timing, robust relay outputs, and straightforward configuration, the Danaher B506-7001 controller is an ideal component for industrial automation systems requiring dependable, repeatable timing control.
