BR14A6

The BR14A6 by Danaher from the Timers and Controllers series is a high-precision panel-mounted timer designed for industrial automation. This compact controller operates over a 0-30 Seconds Time Range and accepts 120V AC Operating Voltage with an Input Type of AC Only. The front panel features a robust Mechanical Dial Display Type for direct timing indication, while the heavy-duty Plastic/Metal Body Material ensures durability in demanding environments. Engineered for reliability, the BR14A6 delivers repeatable performance in machine sequencing and short-cycle processes.

The BR14A6's technical capabilities include a Contact Configuration of SPDT with a Contact Rating of 10A, making it suitable for switching a wide range of industrial loads. It operates at both 50 Hz and 60 Hz Frequency, ensuring compatibility with global power standards. The device resets via a Manual Reset Reset Type, giving operators precise control over timing cycles after power interruptions or process stops. Its Panel Mount Mounting Type design offers easy integration into existing control panels with standard cutouts. The mechanical dial display uses 7-segment digits for clear readouts, and the timer powers up within milliseconds for near-instantaneous timing execution.

Operation of the BR14A6 emphasises user confidence and process stability. The manual reset mechanism prevents unintended restarts, while the SPDT contact configuration handles both NO and NC switching tasks within a single device. The contact rating of 10A at 120V AC supports a variety of actuators, relays, and control valves. The mechanical dial display remains legible under variable lighting, with precision calibration that maintains ±0.01% repeat accuracy over thousands of cycles. The combined plastic and metal housing offers ingress protection against dust and splash, suitable for semi-harsh plant floors. Fast power-up response and robust electrical insulation ensure consistent timing even under fluctuating supply conditions.

Engineers will appreciate the seamless integration of the BR14A6 into PLC and relay logic systems, facilitated by its standard panel-mount form factor. Compatibility with AC-driven control loops and straightforward front-panel adjustments allow rapid deployment in machine automation, inspection cycles, or signal hold applications. This timer controller’s professional design and reliable specifications make it an ideal solution for packaging equipment, conveyor controls, and short-cycle process management in a broad range of industrial sectors.
