S image of HA5250050004129

HA5250050004129

by Danaher
$1,155.00 - $1,155.00
$1,155.00
$1,155.00 - $1,155.00
$1,155.00
Condition: Refurbished

In Stock, Ships Fast

The HA5250050004129 encoder from Danaher is part of the Dynapar Encoders series. It delivers 500 pulses per revolution, features two-channel TTL quadrature output with optional index, supports shaft speeds up to 5000 RPM, and offers MS, M12, or cable exit termination. The encoder withstands temperatures from -40°C to +100°C and shock loads up to 50 g with 11 ms duration. Its solid shaft and square flange design ensure robust mechanical integration.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Electrical Outputs

OC 40 mA, PP 40 mA, 7272 Diff 40 mA, 4469 Diff 100 mA

EMC & Protection

EN61326‑1; reverse polarity and short circuit protected

Frequency Response

≥100 kHz (Index ≥75 kHz at extended temp)

Humidity

up to 98% non‑condensing

Index Phase

180° ±18° electrical, gated with B low

Input Power

5‑26 VDC, 80 mA max (excl. outputs)

Max Shaft Speed

5000 RPM

Operating Temperature

0 to +70°C (std), 0 to +85°C (ext)

Output Format

Quadrature AB with optional Z and complementary outputs

Phase Sense

A leads B for CW rotation (seen from shaft end)

Quadrature Phase

90° ±22.5° electrical

Shaft Load

radial 35 lbs, axial 40 lbs

Shaft Size

1/4" and 3/8"

Shock

50 G, 11 ms

Storage Temperature

-40 to +90°C

Termination Options

MS, M12 or cable exit

Vibration

5 to 2000 Hz

Waveform

Squarewave, rise/fall <1 µs into 1000 pF load
