HG102A6
by Danaher
The Danaher HG102A6 timer from Danaher’s Timers series represents a high-precision solution for repeat cycle applications, combining robust construction with a compact footprint. Engineered for a 150-second range with a 2-second minimum setting, the HG102A6 excels in operations requiring short-time intervals and rapid cycling. This versatile timer features two concentric dials for independent ON and OFF timing adjustments, supported by a 120 VAC, 60 Hz power supply that requires no additional transformers or converters. Its design implements a repeat cycle, two-circuit configuration allowing simultaneous control of dual output contacts. The product arrives in a standard CYCL-FLEX plug-in casing, facilitating straightforward panel integration and rapid replacement in time-sensitive environments.
Performance is driven by a 2.5 VAC synchronous motor coupled to a precision gearing transmission that rotates the internal cam, ensuring consistent timing accuracy and repeatability over its entire dial range. Users can customize dwell and overlap intervals up to 2 seconds maximum, enhancing flexibility for specialized timing sequences. The mechanical cam profile and gearing withstand high cycle rates, enabling reliable operation without excessive wear. Dual circuitry simplifies wiring for complex control loops, allowing independent timing profiles on each contact set. This combination of mechanical precision and electrical simplicity delivers stable operation even under fluctuating supply conditions.
Built to endure rigorous industrial environments, the HG102A6 boasts a shock- and vibration-resistant casing that meets stringent durability standards. Its operating temperature rating spans from -20°F to 140°F, ensuring functionality in cold storage and high-heat applications alike. With an expected life of 10,000,000 operations, downtime is minimized and maintenance intervals are extended. The plug-in module format guarantees quick replacement and seamless integration into existing control systems. Ideal for use in packaging machinery, conveyor control, batch processing, and process automation, the HG102A6 offers dependable timing performance that enhances operational efficiency and uptime.
