S image of HP54A601

HP54A601

by Danaher
$567.99 - $1,421.42
$567.99
$567.99 - $1,421.42
$567.99

In Stock, Ships 1 - 3 Days

The Danaher HP54A601 timer from the Timers and Controllers series is a versatile cycl-flex unit offering a time range of 5 sec to 60 hr and reset time of 0.5 sec. It operates on 120V or 240V AC, 60 Hz with a voltage tolerance of +10%/-15% and delivers an output rating of 10A @ 120 VAC, 5A @ 240 VAC. Built with a synchronous motor, it achieves repeat accuracy of ±0.05 sec to ±18 min, an average pull-in time of 28 ms, and an average drop-out time of 17 ms. The 15-terminal ABS housing withstands vibration resistance up to 2.5 G, 10-900 Hz. With a power consumption of 10.5 VA clutch and 2.45 VA motor, and weighing 2 lb 14 oz, it meets UL, CSA, and FM standards for industrial automation.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Average Drop-out Time

17 ms

Average Pull-in Time

28 ms

Electrical Lifetime

250,000 ops @ full load; 5M cycles @ 1A

Minimum Setting

1/6 sec to 2 hr

Output Rating

10A @ 120 VAC, 5A @ 240 VAC (resistive)

Power Consumption (clutch)

10.5 VA

Power Consumption (motor)

2.45 VA @ 120 VAC

Repeat Accuracy

±0.05 sec to ±18 min

Reset Time

0.5 sec at max setting

Supply Voltage

120V or 240V AC, 60 Hz

Temperature Range

-18°C to +60°C

Time Range

5 sec to 60 hr

Vibration Resistance

2.5 G, 10–900 Hz

Voltage Tolerance

+10%, -15%

Weight

2 lb 14 oz
