S image of HS35R006084P7

HS35R006084P7

by Danaher
$1,099.97 - $1,099.97
$1,099.97
$1,099.97 - $1,099.97
$1,099.97
Condition: Refurbished

In Stock, Ships 1 - 3 Days

The HS35R006084P7 from Danaher is a hollow shaft encoder with NEMA4/IP66 protection and supports 1 to 2500 pulses per revolution. Part of the Dynapar Encoders series, it runs on 4.5–26 VDC and processes at 100 kHz. The encoder resists 50 G shock and mounts directly with electrical isolation.

It offers open collector, push-pull and differential outputs with 100 mA capacity. It endures 40 lb radial and 30 lb axial shaft loads. Operating temp -40 °C to +70 °C, extended to +100 °C above 1800 RPM.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Bearing Life (1800 RPM)

128,000 h

Bearing Life (3600 RPM)

80,000 h

Code Disk

Unbreakable

Electrical Protection

Overvoltage, reverse voltage, short circuit

Enclosure Rating

NEMA4/IP66 (dust proof, washdown)

Frequency Response

≥100 kHz

Input Power

4.5–26 VDC, ≤100 mA

Mounting

Electrically isolated, direct shaft mount

Operating Temp (Extended)

0°C to +100°C (derate >1800 RPM)

Operating Temp (Standard)

–40°C to +70°C

Output Option 4469

Differential line driver, 100 mA sink/source

Output Option 7272

Push-pull, 40 mA sink/source

Output Option 7273

Open collector, 40 mA sink max

Resolution

1–2500 PPR

Shaft Bore Tolerance

+0.0003″ to +0.0005″ (0.008–0.013 mm)

Shaft Loading

40 lb radial, 30 lb axial

Shaft Sealing

Hollowshaft with seals at both ends

Shaft Speed (Max)

3600 RPM (derate >1800 RPM)

Shock & Vibration

50 G shock (11 ms); 5–2000 Hz @20 G
