Bearing life (L10)
2 billion revolutions
Bore size options
0.250″ or 0.375″
Encoder resolutions
200, 400 or 500 lines/rev
Frequency accuracy
≤3 arc min (zero runout)
Frequency modulation (comp outputs)
±1.0% max
Frequency modulation at 50 kHz
±0.5% max
Frequency response
100 kHz
Installed encoder model
C2006 (200 lines/rev)
Max acceleration
100,000 rad/sec²
Max shaft load
9.0 lb (4.1 kg)
Max slew speeds
15,000 rpm; 7,000 rpm (selected configs)
Min holding torque
450 oz·in (318 N·cm)
Min residual torque
25 oz·in (11 N·cm)
Motor family
SLO-SYN DC43 series
Motor weight
7.8 lb (3.5 kg)
Mounting holes
2×#4-40 on 1.812″ BC
Output format
Dual-channel quadrature
Rotor inertia
0.0265 oz·in·s² (1.87 kg·cm²)
Supply voltage
5 VDC
