The M.1017.3138 is a Block IO Analog Module by Danaher, part of the Block IO Analog Modules series, offering 4000 FU/electrical rev resolver resolution and a max velocity of 15,000 eRPM. It provides 15 Vp-p (5.3 Vrms) output at 4 kHz excitation, powered by 24 VDC (200 mA). Featuring 2×18-pin screw terminals and supporting cable runs to 100 ft, it ensures precise industrial feedback.
Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.
Accuracy (constant temp)
±12 arcmin
Accuracy drift over temperature
±5.4 arcmin/10°F
Cable length (module→terminal block)
Max 6 ft (18 AWG)
Cable length (terminal block→resolver)
Max 100 ft (twisted pair)
Excitation method
2-phase quadrature
Field-side connector
2×18-pin screw terminals
Frequency
4 kHz
Inrush current
2.5 A for 250 μs at power on
Max current per channel
100 mA
Max velocity
15,000 eRPM (1×10⁶ FU/s)
Output voltage
15 Vp-p (5.3 Vrms)
Power supply
24 V DC (20–30 V), 200 mA
Resolution, potentiometer
1000 FU/elec rev
Resolution, resolver
4000 FU/elec rev
Resolver transformer ratio
0.5:1–1.0:1
Stored position range
0–3999 FU
