S image of M.1300.7372

M.1300.7372

by Danaher
$2,487.50 - $4,852.16
$2,487.50
$2,487.50 - $4,852.16
$2,487.50

In Stock, Ships 1 - 3 Days

The M.1300.7372 module from Danaher is part of the Block IO Analog Modules series and features optical isolation with transient suppression on the 24 V supply. It supports a supply voltage range of 20–30 VDC, a maximum allowable voltage of 30 VDC, and features two 18-pin screw terminal field connectors. Its inrush current peaks at 2.5 A for 250 µs and off-state leakage current is 0.75 mA. The module draws 100 mA at a nominal 24 VDC.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Field Side Connectors

2 × 18-pin screw terminal connectors

Guaranteed Off Voltage

5 VDC

Guaranteed On Voltage

15 VDC

Ih Max

7.5 mA

Ih Min

2.8 mA

Input Off Signal

0 VDC

Input On Signal

24 VDC nominal

Inrush Current

2.5 A for 250 µs at power-on

Maximum Allowable Voltage (Uh Max)

30 VDC

Off-State Leakage Current (It Min)

0.75 mA

Optical Isolation

Between logic & field sides

Status LEDs

Data In, Data Out, Configured, Power

Supply Current

100 mA @ 24 VDC

Supply Voltage Range

20–30 VDC

Transient Suppression

On 24 V supply

Turn-Off Time Delay

<=1 ms

Turn-On Time Delay

<=1 ms
