RZS01.1-6-010

Request a quote
The RZS01.1-6-010 is a sinusoidal filter produced by Bosch Rexroth Indramat, a prominent supplier of industrial automation parts. This model forms part of their RZS series and is designed to moderate power peaks and surges, reducing strain on winding insulation. It is engineered for operation with three-phase power connections at nominal connecting voltages of AC 380 - 400 V. The unit reduces motor losses during high-speed operation and diminishes low-frequency voltages interference in the power line. It has a 10 A nominal current and provides output at a 200 Hz frequency range. The suggested maximum cable length is 400 meters, cumulatively for all connected motor cables. The module should be installed on a flat surface, has specific input and output terminals, and should be operated within 0 to +40 degree Celsius. Cooling is achievable via natural convection or fan, and only authorized personnel may commission the device.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Model: RZS01.1-6-010
  • Product Category: Sinusoidal Filter
  • Function: Reduce excessive losses in the motor due to high-speed operation
  • Nominal Connection Voltage: AC 380 - 400 V
  • Nominal Current: 10 A
  • Output Frequency Range: 200 Hz
  • Maximum Cable Length: 400 meters
  • Mounting Surface: Plain flat surface
  • Input Terminals: U1, V1, W1
  • Output Terminals: U2, V2, W2
  • Operating Temperature Range: 0 to +40 degree Celsius
  • Cooling Method: Natural convection
  • Air Quality for Cooling: Free from aggressive and electrically charged gases
  • Installation Guidelines: Install in dust and pollution free environment
  • Commissioning: Should only be performed by qualified people
