S20260-VTS

by Danaher
Original price $2,944.50 - Original price $2,944.50
Original price
$2,944.50
$2,944.50 - $2,944.50
Current price $2,944.50
Available, Shipping Varies
Danaher Motion's S20260-VTS is a high-efficiency servo drive belonging to the S200 series. It is characterized by features such as 1.5 ARMS continuous current, 4.5 ARMS peak current, and 120/240 VAC voltage. This model, part of the VTS (analog velocity and torque base drive) series, supports SFD/Halls feedback and offers superior performance against other brushless servo drives. Its smart feedback and high bandwidth facilitate plug-and-play commissioning, thus eradicating the need for servo loop tuning in most scenarios. The S20260-VTS is designed for operation in environments up 1500 meters above sea level, with temperatures ranging between 0 to 40 degrees Celsius. For storage, temperatures should range from -35 to 85 degrees Celsius with a humidity level between 10% and 90%. Weighing approximately 1.86 pounds, it should be installed vertically in a sturdy cabinet, ensuring sufficient space for air circulation and cooling.
30 Day Warranty
Technical Specifications
  • Manufacturer: Danaher Motion
  • Product Model: S20260-VTS
  • Product Family: S200 Servo drives
  • Model Number: VTS (analog velocity and torque base drive)
  • Feedback Support: SFD/Halls
  • Continuous Current: 1.5 ARMS
  • Peak Current: 4.5 ARMS
  • Voltage: 120/240 VAC
  • Installation Altitude: Less than 1500 meters
  • Operating Temperature: 0 to 40 degrees
  • Storage Temperature: -35 to 85 degrees
  • Humidity Range: 10% to 90%
  • Weight: 1.86 pounds
  • Mounting Orientation: Vertical
