SS950-16010

The SS950-16010 timer from Danaher is a precision control device in the Timers and Controllers series, designed for demanding industrial automation environments. It features a compact Overall Width of 48 mm and Overall Height of 48 mm, combined with a Depth of 85 mm for efficient panel integration. The front display employs a Dual line, 4 digit, 7 segment LED, 8 mm high configuration to present clear status information at a glance. Power is supplied by a versatile 90-240 VAC, 50/60 Hz source, while the Front Panel Protection of IEC IP65 rating ensures robust resistance to dust and water ingress. Its lightweight Weight of 100 grams minimizes load on mounting surfaces without sacrificing durability.

Technical performance is highlighted by an ultra-fast Input Activation Time of 21 ms and a stable Input Impedance of 10 kΩ, enabling precise timing cycles. The device supports an Output Type of NPN open collector, opto-isolated, delivering a Maximum Output Current of 30 mA at up to Maximum Output Voltage of 30 VDC. Power draw remains economical at under Power Consumption of <10 VA @ 240 VAC, making it suitable for extensive networked installations. As a Panel Mount unit, it simplifies installation and maintenance, while the rugged design preserves performance in high-vibration scenarios.

Operational reliability extends across a temperature range from 0 °C to 55 °C, with full functional stability under industrial load conditions. The IEC IP65 protected front panel and sealed housing guard internal components against moisture and particulate ingress, ensuring uninterrupted operation on factory floors. With an intuitive LED display and clear labeling, operators can rapidly diagnose status, adjust settings, and confirm output signals without specialized tools. The device’s low mass and compact form factor reduce mechanical stress on control cabinets and support swift retrofits or system expansions.

Integration into control architectures is seamless, thanks to standardized dimensions and universally compatible electrical interfaces. The SS950-16010 works in harmony with PLCs, HMIs, and safety relays to manage cyclical processes, event sequencing, and delay functions. Its robust opto-isolated outputs provide protection against ground loops and electrical noise, enabling deployment in high-EMI environments. Engineered by Danaher for flexibility and long-term service, this timer is ideal for packaging lines, conveyor controls, test equipment, and automated assembly systems where precision timing and dependable performance are paramount.
