S image of T003-0004

T003-0004

by Danaher
$1,768.00 - $1,768.00
$1,768.00
$1,768.00 - $1,768.00
$1,768.00
Condition: Refurbished

Available, Shipping Varies

The T003-0004 from Danaher offers 8 high-precision ADC channels and a resolution of 16 bits for accurate signal capture. Part of the Synqnet Boards series, this board supports an analog input voltage range of ±10 V, low-pass noise filtering, and a signal bandwidth from DC to 17 kHz.

It features VHDCI connectors for PCI/CPCI installation, an analog input impedance of 100 kΩ, and a DC offset of 15 mV. It achieves an ADC conversion time of 10 µs with a gain uncertainty of 0.5%.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

2 - 4 Days
Handling Time

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

-12v Supply

-12 VDC ± 10%

+12v Supply

+12 VDC ± 10%

+3.3v Supply

+3.3 VDC ± 10%

+5v Supply

+5 VDC ± 5%

Adc Conversion Time

10 µs

Adc Resolution

16 bits

Analog Input Impedance

100 kΩ

Analog Input Voltage Range

±10 V (max dynamic range)

Connector Type

VHDCI connectors for PCI/CPCI installation

Conversion Rate

Once per servo cycle

Dc Offset

15 mV (max on 10 V range)

Gain Uncertainty

0.5% (max on 10 V range)

Nonlinearity

6 LSB

Number Of Adc Channels

8 channels

Signal Bandwidth

DC to 17 kHz (low-pass noise filtering)
