TDA 1.3-100-3-AP0

Request a quote
The TDA 1.3-100-3-AP0, created by Bosch Rexroth Indramat, is a main spindle drive controller celebrated for its precise position control capabilities due to its highly responsive control system. It can efficiently control the speed and position of 2AD asynchronous and 1MB frameless motors with continuous power output varying from 3 kW to 10 kW. The TDA 1.3-100-3-AP0 can operate over a broad speed range, integrate seamlessly with other controllers and drive systems, and adjust to specific CNC machine tasks. The internal position control circuit performs with exceptional resolution, even managing to automatically control the spindle up to the 1/4000 000th revolution. In addition, this device can convert the a.c. main spindle drive into a servo axis and accurately detect the rotor position, even at low speeds. The device operates through a microprocessor and features an AS programming module to synchronize the controller with the main spindle motor.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product type: Main spindle drive controller
  • Model: TDA 1.3-100-3-AP0
  • Main function: Position control capabilities
  • Compatibility: Compatible with 2AD asynchronous and 1MB frameless motors
  • Continuous power output: Between 3 kW and 10 kW
  • Additional controller use: Can be used with feed axes controllers
  • Customization: Drives can be matched to specific CNC machine tasks
  • Speed range: Operates across a wide speed range
  • Position control circuit: Has an internal position control with high resolution
  • Resolution: As high as the 1/ 4000 000th revolution
  • Main spindle motor assistance: Assisted by a high resolution feedback motor for precise control
  • Rotor position detection: Can detect the rotor position efficiently at low speeds
  • Rotor control resolution: 1/2000 000 revolutions
  • Programming module: Comes with the AS programming module
  • Microprocessor control: Controlled through a microprocessor
