VMA 021KB 001-D

Request a quote
The product is the VMA 021KB 001-D, a high-dynamics power supply module by Rexroth Indramat. Designed for industrial applications, this module is used to operate servo drives, motors, and controls. It has an operational supply voltage of 400 - 460 V and an air cooling feature. It also hosts an internally integrated ballast switch with a 17-second repetition time. The model is constructed in compact mechanics and is a standard variant in the VMA Servodyn-D series. The rated voltage runs at 400 Volts (50Hz frequency), the direct current link voltage is regulated at 670 Volts, and it has a rated power of 16kVA. Its braking energy is a product of its rotational force and braking procedures over time with one-time braking, with energy at 6.5 kWs and continuous energy at 400 Watts. This module operates between sea level and an altitude of 1,000 meters and weighs 15 kgs.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Name: VMA 021KB 001-D
  • Product Type: High-dynamics power supply module
  • Supply Voltage: 400 – 460 V
  • Cooling Mechanism: Standard air-cooling
  • Equipped with Ballast Switch: Yes
  • Ballast Switch Repetition Time: 17 seconds
  • Module Type: Compact mechanics
  • Digital Interface: No
  • Rated Voltage: 400 Volts at 50 Hz
  • DC Link Voltage: 670 Volts
  • Rated Current at 45 degrees C: 23 Amperes
  • Rated Power at 45 degrees C: 16 kVA
  • Peak Output Power: 20 kVA
  • Weight: 15 kgs
  • External Power Supply Voltage: 24 VDC
  • Current Input: 1 Amp
  • Braking Energy: 6.5 kWs
  • Continuous Braking Power: 400 Watts
  • Operating Altitude: 0 – 1000 meters above sea level
