PPC-R22.1N-T-Q1-V1-NN-FW

by Bosch Rexroth Indramat
Request a quote
Produced by Bosch Rexroth Indramat, the PPC-R22.1N-T-Q1-V1-NN-FW is part of the Rexroth VisualMotion 10 series, used for multi-axis logic and motion controls. Setup is via the VisualMotion Toolkit software, connected through the front panel's serial programming interface. This system defaults to a 9600 baud rate, which can be increased to 115,200 baud. It's compatible with a standard R3-232 interface cable for PC communication. Designed for applications such as general motion control and robotics, features include a DeviceNet master module, Ethernet and ARCNET support. The front panel also houses a communication serial port for RS-485 / RS-422 / RS-232 with variable baud rates. It features a fiber optic SERCOS interface, and uses VisualMotion's GPP 10 firmware. The system communicates with other modules over a backplane bus, and its enclosure has an IP20 environmental protection rating. The input voltage range is 19.2 to 30 Volts DC, with a preferred input of 24 Volts DC.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: Rexroth VisualMotion 10 series multi-axis logic/motion control system
  • Configuration Software: VisualMotion Toolkit
  • Communication Method: Serial programming interface
  • Default Baud Rate: 9600
  • Max Baud Rate: 115200
  • Standard Interface Cable: IKB0005 cable
  • Form Factor: Reco 02
  • Applications: General motion control, robotics, and multiple master electronic line shafting
  • Key Features: DeviceNet master module, Ethernet interface and support for ARCNET
  • Memory Expansion: No
  • Additional Communication Port: RS-485/RS-422/RS-232
  • Variable Baud Rates: 9600 to 115200
  • SERCOS Interface: 2, 4, 8, and 16 Mbaud
  • Firmware Compatibility: VisualMotion’s GPP 10
  • Placement: Reco 02 racks from Bosch Rexroth
  • Backplane Bus Communication: Yes
  • Environmental Protection Rating: IP20 according to EN 60529
  • Maximum Power Cable Size: 1.5 mm2
  • Input Voltage Range: 19.2 to 30 Volts DC (including ripples)
  • Nominal Input Value: 24 Volts DC.
