R911280716
The R911280716 (MKE096B-047-KG1-KN), produced by Bosch Rexroth Indramat, is a synchronous servo motor optimally designed for use in hazardous environments. Compliant with ATEX and UL/CSA specifications, it serves as a versatile drive motor, ideal for various industries including chemical processing, mining, and woodworking. It features an explosion-proof casing that guarantees safe operation under tough conditions. Specifications include a frame size of 096, frame length of B, and winding codes of 047.
This high-performing motor can generate a peak torque of 43 Nm and a maximum speed of 4,500 rpm, with four pole pairs. It has an IP 65 rating denoting its strong resistance to dust and water jets. The plain shaft is configured with a shaft sealing ring and an absolute multiturn encoder featuring Hiperface and 128 increments. The encoder's memory makes the start-up process swift and allows the motor to smoothly align with its corresponding drive. Furthermore, its torque-to-inertia mass ratio is designed for high dynamics and smooth operation. Power loss scenarios utilize an electrically released holding brake with 11 Nm of holding torque. The motor's brushless design and grease-lubricated bearings simplify maintenance tasks. For optimal performance, the R911280716 (MKE096B-047-KG1-KN) should be operated below 40o C in environments less than 1000m above sea level.
