series image of VT 3000 S 35-R1

VT 3000 S 35-R1

by Bosch Rexroth Indramat
Request a quote
The VT 3000 S 35-R1, a valve amplifier by Bosch Rexroth Indramat, has an operating voltage of 24VDC with a maximum power consumption of 50VA. It utilizes a 32-pin terminal strip for connection and operates between 0 to 50 degrees Celsius, with a storage temperature ranging from -25 to 85 degrees. This versatile unit can control either directly or indirectly operated proportional valves without electrical position feedback. It’s equipped with four command call-ups, each indicated by LEDs and controlled by external potentiometers or direct voltage. Input is at +/-9V, and built in features include a step function generator and two pulsed output stages. It operates on a priority model with a relay K6, allowing for voltage supply to command values. Moreover, available adjustments to the ramp time can be made using potentiometers via jumpers ranging from J1 to J5.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Type: Valve Amplifier
  • Model: VT 3000 S 35-R1
  • Operating Voltage: 24VDC +60% -5%
  • Power Consumption<: 50VA
  • Ramp Time: 30ms to 1-5 seconds
  • Connection Type: 32-pin terminal strip
  • Operating Temperature: 0 to 50 degrees
  • Storage Temperature: -25 to 85 degrees
  • Control Function: Can control a directly operated proportional valve or a pilot operated one without the need of electrical position feedback
  • Number of Command Calls: Four, highlighted by LEDs
  • Input Type: External potentiometers or directly through controlled voltages
  • Input Usage: +/-9V +/-100% input
  • Additional Features: Step function generator, Two pulsed output stages, Differential input
  • Cardholder: Single, without power pack
  • Ramp Time Adjustability: By potentiometers, through use of jumpers J1 to J5
  • Priority Command Model: Yes
  • Relay: Relay K6, switches on with smoothed 24VDC.
