VT-MSPA2-2X-A5-000-000

Original price $3,535.00 - Original price $3,535.00
Original price
$3,535.00
$3,535.00 - $3,535.00
Current price $3,535.00
In Stock, Shipping Varies
Request a quote
The Bosch Rexroth Indramat VT-MSPA2-2X-A5-000-000 is a high-performing valve amplifier for proportional valves that lack electrical feedback. It is engineered to optimize industrial hydraulic applications, with push buttons enabling user-friendly adjustments to all valve parameters. The command value input of the model ranges from 0 to 10 V, offering reverse polarity protection with actual current value and internal current command measuring capabilities. The system includes LED status displays and separately adjustable ramp generators for enhanced control and visibility. Further, the system allows for command value adjustments and possesses an integrated characteristic curve generator. Mounted on top hat rails, the amplifier uses three tension spring plug-in connectors and operates at a supply voltage of 24 V, with a maximum power consumption of less than 48 W. With a fast startup time, the VT-MSPA2-2X-A5-000-000 is protected by a 3.15 A time-lag electrical fuse and can operate in temperatures up to 60 °C.
30 Day Warranty
Technical Specifications
  • Manufacturer: Bosch Rexroth Indramat
  • Product Code: VT-MSPA2-2X-A5-000-000
  • Type: Valve amplifier for proportional valves without electrical feedback
  • Application: Industrial hydraulic applications
  • Command Value Input: 0 to 10 V
  • Protection: Reverse polarity protection for operating voltage
  • Features: Measuring sockets for actual current value and internal current command, LED status displays, Adjustable ramp generator for up and down modes, Command value adjustment, Characteristic curve generator
  • Assembly: Top hat rails
  • Electrical Connection: Three tension spring plug-in connectors
  • Supply Voltage: 24 V
  • Design: Modular
  • Operating Voltage: 24 V
  • Voltage Limits: 18-36 V
  • Maximum Power Consumption: 48 W
  • Maximum Current Consumption: 2 A
  • Protection: 3.15 A time-lag electrical fuse
  • Start-Up Time: Less than 1 second
  • Connections: 12 spring type terminals that are detachable
  • Weight: 0.14 kg
  • Maximum Operating Temperature: 60 °C.
