series image of AX5140-0000-0202

AX5140-0000-0202

by Beckhoff
$0
$8,020.01 - $8,020.01
$8,020.01
$8,020.01 - $8,020.01
$8,020.01
Available, Shipping Varies
 More payment options
The Beckhoff AX5140-0000-0202 is a compact, single-channel digital servo drive from the AX51xx series, featuring a high-speed EtherCAT communication system for seamless integration with PC-based control technology. Its integrated control technology positions it as a dynamic device with quick response times. The drive is designed to connect with other AX500 devices through AX-Bridge control, allowing the formation of a multi-axis system. It is versatile and can connect to various types of motors such as synchronous, linear, torque, and asynchronous ones. It operates within a wide current range of 3A to 40A and a supply voltage of 3x100 - 480V AC ±10%. The servo drive includes multi-feedback interfaces, DC-link and breaking voltage energy controls, and supports multiple communication protocols. Safety features like STO, SS1, and TwinSAFE are built in to prevent inadvertent restarts of the drive axis. Its compact size makes it suitable for control cabinet installation and economical for OEM and multi-axis applications.
30 Day Warranty
Technical Specifications
  • Manufacturer: Beckhoff
  • Product Name: AX5140-0000-0202
  • Product Type: Single-channel Digital Compact Servo Drive
  • Communication System: EtherCAT
  • Control Technology: Integrated
  • Control Type: AX-Bridge
  • Compatible Motor Types: Synchronous, Linear, Torque, Asynchronous
  • Special Feature: SERCOS™ Profile for Servo Drives
  • Protection Class: IP20
  • Current Range: 3 A to 40 A
  • Supply Voltage: 3 x 100…480 V AC ±10 %
  • Special Feature: DC-link and Breaking Voltage Energy Management
  • Feedback Interface: Multi-feedback
  • Control Support: Analog Torque/ Velocity/ Position, Pulse & Direction, Stored Program, Streaming Commands, Fieldbus, Industrial Ethernet Control
  • Design: Compact
  • Ideal Applications: OEM and Multi-axis
  • Installation: Simple Control Cabinet (300 mm depth)
  • Special Feature: Integrated STO, SS1, and TwinSAFE Safety Functions.
