S image of LSM34N-10-602-E2-OKA

LSM34N-10-602-E2-OKA

by Kollmorgen
$0.00 - $0.00
Request a Quote
$0.00 - $0.00
Request a Quote

Request a quote

Add a Message
The LSM34N-10-602-E2-OKA, manufactured by Kollmorgen, is a brushless servo motor that stands out for its high operational reliability and maintenance-free operation, particularly when paired with Kollmorgen's recommended equipment. Structured for high acceleration and peak torque applications, this model thrives even in challenging environments thanks to its superior protection rating. It is commonly utilised for developing smart conveyors and in other high duty cycle applications in multiple industries. Key features of the LSM34N-10-602-E2-OKA include an E2 2000 line incremental encoder for accurate position detection and a temperature sensor for protection against overvoltage. This model also contains a high-energy neodymium magnet rotor with a keyway for boosting acceleration. Operating at a rated power of AC 230 V and a nominal speed of 6000 rpm, this servo motor delivers a continuous torque of 10 lb.-in at 3.1 A rated current. The motor's cooling mechanism is based on natural convection.

Contact Us

Email: sales@servosupplier.com
Phone Number: 1-888-551-3082
International: 1-919-443-0207
Fax: 1-919-867-6204

Servo Supplier is not an authorized distributor. We sell new surplus and refurbished products. All warranties are with Servo Supplier and not the manufacturer.

Military Grade
Packaging

30 Day Warranty

Shipping Options

Payment Options

Technical Specifications

Manufacturer

Kollmorgen

Model Number

LSM34N-10-602-E2-OKA

Product Type

Brushless Servo Motor

Primary Usage

High acceleration and peak torque applications

Additional Usage

Smart conveyors and various high duty cycle applications

Encoder

E2 2000 line incremental encoder for position detection

Continuous Torque

10 lb.-in (1.1 Nm)

Rated Current

3.1 A

Nominal Speed

6000 rpm

Peak Corner Speed

3000 rpm

Rated Power

AC 230 V

Installation Requirements

With respective MMC servo drive

Temperature Sensor

Yes, for protection against overvoltage

Magnet Rotor

High-energy neodymium with a keyway

Mounting Option

Direct pinion

Manufacturing Standards

ISO9000

Weight

2.3 kg

Winding Inductance

23.8 mH

Cooling Method

Natural Convection
