EL6652

Original price $1,770.60 - Original price $1,770.60
Original price
$1,770.60
$1,770.60 - $1,770.60
Current price $1,770.60
In Stock, Ships Today
Request a quote
The Beckhoff EL6652 is an EtherNet/IP master terminal central to Beckhoff's EtherCAT technology. This solution, developed for industrial automation, harnesses the power of real-time computing within a cutting-edge industrial Ethernet system. The terminal allows the configuration of an Ethernet/IP unit by a Beckhoff EtherCAT master, enabling diverse process data handling. The EL6652, featuring 2 switched-port Ethernet connections, can interface with up to 16 other EtherNet/IP devices. Its data capabilities include a maximum of 1 kilobyte (input and output). With a pair of RJ45-port 100BASE-TX Ethernet interface, it uses a supplied 5V voltage via bus coupler. The terminal operates efficiently in temperatures of 0-55 Celsius and at a humidity below 95 percent (without condensation). Certified by CE and UL, the EL6652 is universal, however its installation should avoid liquid-prone areas. It also grants Unicast and Multicast transmission.
30 Day Warranty
Technical Specifications
  • Manufacturer: Beckhoff
  • Technology: EtherCAT
  • Application: Industrial Automation
  • Product Type: EtherNet/IP Master Terminal
  • Ethernet Connection: Switched 2-port
  • Maximum Slave Nodes: 16
  • Max Data Length: 1 kilobyte (input and output)
  • Ethernet Interface: 100BASE-TX
  • Ports: 2 RJ 45
  • Operating Voltage: 5 Volts (via bus coupler)
  • Operating Temperature: 0 to 55 degrees Celsius
  • Relative Humidity: 95 percent max (non-condensing)
  • Approvals: CE and UL
  • Mounting: Cabinet or non-liquid prone environments
  • Special Features: Unicast and Multicast transmission capability
